When laying pipes and wiring, encountering nodes or making a 45° turn at the corner of a wall, connect/dock the two ends of grooved pipe materials with the same nominal diameter. The angle is 45 degrees, which means it can change the flow direction of the fluid and realize the flexible layout of the pipeline system. Our 45 degree steel elbow is made of stainless steel material, so it has excellent corrosion resistance and high pressure resistance, suitable for a variety of harsh environments. The 45 degree steel elbow is designed with grooves, which makes installation and connection more convenient, usually through clamps, sealing rings and other components to quickly connect with the pipeline system.
| NO. | Size | External Dia.(mm) |
| 1 | 5'' | 133 |
| 2 | 6'' | 159 |
| 3 | 8'' | 219 |
| 4 | 10'' | 273 |
| 5 | 12'' | 325 |
Materials and corrosion resistance
Stainless steel grooved 45 degree steel elbow In a humid and corrosive environment, the stainless steel elbow can maintain its performance for a long time and is not easy to rust or corrode, thus extending the service life of the system.
The corrosion resistance of the 45-degree carbon steel welded elbow is relatively poor. In a corrosive environment, the carbon steel elbow may rust and wear more quickly, affecting the performance and life of the system.
Connection method and installation convenience
Stainless steel grooved 45 degree steel elbow can be quickly and easily connected to the pipeline system through components such as clamps and sealing rings, greatly saving installation time and cost.
The welding process of the 45-degree carbon steel welded elbow is relatively complicated, requiring professional skills and tools, and additional inspection and testing may be required after welding.
Fluid transmission performance
The groove design of the stainless steel grooved 45 degree steel elbow also helps to reduce fluid resistance and improve transmission efficiency.
Although carbon steel elbows can also meet basic requirements in fluid transmission, they may not be as good as stainless steel elbows in some aspects (such as fluid resistance and corrosion resistance) due to the limitations of their materials and connection methods.
Beauty and durability
The stainless steel grooved 45 degree steel elbow has a silvery-white luster and a beautiful appearance. At the same time, its excellent durability also ensures that the appearance will not be affected by wear during long-term use.
The 45-degree carbon steel welded elbow may be affected in appearance due to rust and wear during long-term use. Although it can be protected by coating and other means, stainless steel elbows have more advantages in beauty and durability.
HVAC Systems: Efficient airflow management, 45 degree steel elbow, seamless integration with stainless steel grooved fittings.
Fire Protection: Reliable water distribution, corrosion-resistant 45 degree steel elbow, secure connections with stainless steel grooved fittings.
Plumbing: Smooth directional changes, durable 45 degree steel elbow, easy installation with stainless steel grooved fittings.
Industrial Piping: Robust performance, 45 degree steel elbow, optimal flow in high-pressure environments, compatibility with stainless steel grooved fittings.
